LGT-SM Seismic Geophone

Seismic Geophone

Instruction:

LGT-SM seismic Geophone is designed to offer cost-effective performance in seismic exploration, main parameters controlled within ± 2.5%. Low distortion, combined with durable specifications, provide high-fidelity data in 2-D and 3-D surveys. It has 3-year limited warranty.

Features:

It features stable performance, high fidelity and consistent quality in conventional industrial of coal, Petroleum and natual gas exploration. LGT-SM geophones are used in a various applications that are far removed from their original applications as earthquake detectors, engineering vabrations, perimeters defensing.

Suitable Seismic Geophones:

Type	LGT-SM24	LGT-SM24A
Natural Frequency (Hz)	10±2.5%	10±2.5%
Open Circuit Damping	0.25±2.5%	0.271±2.5%
Close Circuit Damping	0.6+5% (1339Ω)	0.6±2.5%
Close Circuit Damping	0.686＋5％ (1000Ω)	0.6±2.5%
Intrinsic Voltage Sensitivity (V/cm/s)	0.288±2.5％	0.288±2.5％
Sensitivity with Shunt Resistance (V/cm/s)	0.225+5% (1339Ω)	0.227±2.5％
Sensitivity with Shunt Resistance (V/cm/s)	0.209＋5％ (1000Ω)	0.227±2.5％
Coil Resistance(Ω)	375±2.5％	375±2.5％
Close Direct Current Resistance	293 or 273	296±2.5％
Harmonic Distortion	≤0.1%	≤0.1%
Typical Spurious Frequency	≥250	≥250
Moving Mass (g)	11	11.3
Coil Excursion p-p(mm)	2	2
Maintains Fn Specifications to Tilt Angle	≤20	≤20
Core Unit Diameter (mm)	25.4	25.4
Core Unit Height (mm)	32	32
Core Unit Mass (g)	74	74
Operating Temperature	-40 to +90	-40 to +90
Warranty (Year)	3	3

*Longet Equipment Co., Ltd can customize different kind of seismic geophones to meet all the customer's various applications.
